P5 LED Screen for advertising outdoor Low Power Consumption waterproof cabinet 960*960mm

Product Categories

Shen Zhen AVOE Hi-tech Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

P5 LED Screen for advertising outdoor Low Power Consumption waterproof cabinet 960*960mm

Name: P5 LED Screen for advertising outdoor Low Power Consumption waterproof cabinet 960960mm
Brand: AVOE LED
Price: 1 USD

Wholesale P5 LED Screen for advertising outdoor Low Power Consumption waterproof cabinet 960*960mm from china suppliers

Brand Name : AVOE LED

Model Number : AE-P5OFRGB

Certification : CE,UL,CCC,ROHS,GS

Place of Origin : Shen Zhen China

MOQ : 5sqm

Price : Negotiable

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 10K sqm per month

Delivery Time : 10 working days after receiving the payment

Packaging Details : Flight case, Plywood case

Name : Outdoor LED Advertising Screen

Pixel Pitch(mm) : 5

Pixel Density(pixels/㎡) : 40000

Pixel Configuration : SMD2727

Viewing Angle(deg.) : 160(Horizontal), 160(Vertical)

Brightness(nits) : ≥6000

Usage : Outdoor

Screen dimension : Customized Size

Tube chip color : Full Color

Display function : Video,animation,graphics

Brightness : 6500cd/sqm

Warranty : 5 years

Application : Outdoor Advertising Led,Advertising,Outdoor,HOTEL,Advertising/stage rental/Commercial event

Life span : 100000hours

Color : RGB,Full-color

Module size : 320x160mm

Product name : led display screen

Led chip : Kinglight

Cabinet size : 960*960*128mm

Input voltage : AC110V - AC240V

Contact Now

P5 LED Screen for advertising outdoor Low Power Consumption waterproof cabinet 960*960mm

Features

. Uniform color and high contrast ratio,bringing up fresh and natural image
· Low power consumption and fine heat release
· Super wide viewing angle increasing its value by covering more audience
· No deformation under sunlight by the use of anti-UV modules
· Long service time and low attenuation by applying duel channels for heat dissipation
· High protection grade of IP65 achieved by applying duel channels for heat dissipation
· High protection grade of IP65 achieved by patented mask design with waterproot and dustproof fucntion
· Safe and reliable operation ensured by stable signal nad power supply

Parameters

Pixel Pitch(mm)

Pixel Density(pixels/㎡)

40000

Pixel Configuration

SMD2727

Viewing Angle(deg.)

160(Horizontal), 160(Vertical)

Brightness(nits)

≥6000

Grey Level(bit)

12/14/16

Refresh Rate(Hz)

1920/2880/3840

Panel Size(mm)

960(W)×960(H)×130(D)

Panel Size(inch)

37.80(W)×37.80(H)×5.1(D)

Panel Resolution(pixels)

192×192

Panel Material

Aluminum/Iron

Weight(kg/㎡)

≤45/≤55

Module Size(mm)

240(W)×240(H)

Module Size(inch)

9.45(W)×9.45(H)

Module Resolution(pixels)

48×48

Protection Grade(Front/Rear)

IP65/IP54

Serviceability

Front/Rear

Voltage(V)

AC 100~AC 240

Avg.Power Consumption(W/㎡)

175(AC)

Max.Power Consumption(W/㎡)

700(AC)

Operating Temp/Humidity(℃/%RH)

-20~50/10~90

Storage Temp/Humidity(℃/%RH)

-40~60/0~90

Lifetime(Normal Temp)(hours)

100000

Compliant Standard

CE FCC RoHS

Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.

P5 LED Screen for advertising outdoor Low Power Consumption waterproof cabinet 960*960mm

Competitive Advantages:

1. Good quality;
2. Good price;
3. Good 24hours service;
4. Promote delivery;
5. Energy-saving;
6. Small order accepted.

Our serrvices
1. Service before sales
On-site inspect
Professional design
Solution confirmation
Training before operation
Software use
Safe operation
Equipments maintenance
Installation debugging
Installation guidance
On-site debugging
Delivery Confirmation

2. After sale service
Quick response
Prompt question resolving
Service tracing

3. Service concept:
Timeliness, considerateness, integrity, satisfaction service.
We are always insisting on our service concept, and proud of the trust and reputation from our clients.

4. Service Mission
Answer any question; Deal with all the complaint; Prompt customer service
We had developed our service organization by responding to and meeting the diverse and demanding needs of customers by service mission. We had become a cost-effective, highly skilled service organization.

5. Service Goal:
What you have thought about is what we need to do well; We must and will do our best to fulfill our promise. We always bear this service goal in mind. We can't boast the best, yet we will do our best to free customers from worries. When you get problems, we had already put forward solutions before you.
